KINGPINLESS DUAL WHEEL CASTERS

jamshengo 2-95 Series Kingpinless™ Dual Wheel Casters feature all of the benefits of our patented Kingpinless™ raceway and offer twice the capacity load. Dual wheel casters offer high weight capacities with minimal overall heights, better load distribution, floor protection and mobility than single wheel casters. This is a result of spreading the weight over a wider floor area while offering wheel differential action, resulting in less friction between the wheels and the floor, requiring less effort for the caster to swivel. Our 2-95 Series Casters are proudly made in the USA!

OPTIONS
BRAKES
CWB Cam Wheel Brake
PCWB Poly Cam Wheel Brake
SWIVEL LOCKS
DSL Demountable Swivel Lock*
HDSL Heavy Duty Demountable Swivel Lock
LSL L-Type Swivel Lock
SL Swivel Lock
VSL Vertical Swivel Lock
LUBRICATIONS
HT High Temperature Lubrication
LT Low Temperature Lubrication
GUARDS, YOKES, SEALS, FINISHES
FG Foot Guard
HTP High Temperature Paint
NY Notched Yoke
SR Sealed Raceways
SWP Sweeper Brush
WS Wheel Seals
ZP Zinc Plated

*When ordering the Demountable Swivel Lock (DSL), you must also order the Notched Yoke (NY).
**Add 1/4” to the caster’s overall height with the addition of a swivel lock.

Category:
Description
Wheel Diameter Wheel Width Capacity Wheel Type Overall Height Roller Bearing Ball Bearing Tapered Bearing Swivel Lead Approx Weight
6″ 3″ 4000 Durastan 8-3/4″ 2-95-DUR-0630-S 1-9/16″ 24
6″ 3″ 4000 Solid Urethane 8-3/4″ 2-95-MUB-0630-S 1-9/16″ 24
6″ 3″ 4000 Urethane on Iron 8-3/4″ 2-95-UIR-0630-S 2-95-UIT-0630-S 1-9/16″ 33
6″ 3″ 6000 Cast Iron 8-3/4″ 2-95-CIR-0630-S 2-95-CIT-0630-S 1-9/16″ 39
6″ 3″ 14300 Forged Steel 8-3/4″ 2-95-FSR-0630-S 2-95-FST-0630-S 1-9/16″ 55
6″ 3″ 20000 Nylatron HD 8-3/4″ 2-95-NYB-0630-S 1-9/16″ 24
8″ 3″ 1680 Rubber on Iron 10-3/4″ 2-95-RIR-0830-S 2-95-RIT-0830-S 2-1/16″ 50
8″ 3″ 3000 Rubber on Aluminum-EHT 10-3/4″ 2-95-RAB-0830-S-EHT 2-95-RAT-0830-S-EHT 2-1/16″ 40
8″ 3″ 3200 Omega 10-3/4″ 2-95-UOR-0830-S 2-95-UOT-0830-S 2-1/16″ 52
8″ 3″ 3360 Rubber on Iron-EHT 10-3/4″ 2-95-RIR-0830-S-EHT 2-95-RIT-0830-S-EHT 2-1/16″ 50
8″ 3″ 5000 Durastan 10-3/4″ 2-95-DUR-0830-S 2-1/16″ 28
8″ 3″ 5000 Solid Urethane 10-3/4″ 2-95-MUB-0830-S 2-1/16″ 28
8″ 3″ 5000 Urethane on Iron 10-3/4″ 2-95-UIR-0830-S 2-95-UIT-0830-S 2-1/16″ 52
8″ 3″ 6,000 Cast Iron 10-3/4″ 2-95-CIR-0830-S 2-95-CIT-0830-S 2-1/16″ 49
8″ 3″ 11000 Forged Steel 10-3/4″ 2-95-FSR-0830-S 2-95-FST-0830-S 2-1/16″ 56
8″ 3″ 20000 Nylatron HD 10-3/4″ 2-95-NYB-0830-S 2-1/16″ 29
8″ 4″ 7000 Urethane on Iron 10-3/4″ 2-95-UIR-0840-S 2-95-UIT-0840-S 2-1/16″ 64
8″ 4″ 8000 Cast Iron 10-3/4″ 2-95-CIR-0840-S 2-95-CIT-0840-S 2-1/16″ 68
8″ 4″ 20000 Forged Steel 10-3/4″ 2-95-FSR-0840-S 2-95-FST-0840-S 2-1/16″ 88
8″ 4″ 20000 Nylatron HD 10-3/4″ 2-95-NYB-0840-S 2-1/16″ 40
10″ 3″ 2000 Rubber on Iron 12-3/4″ 2-95-RIR-1030-S 2-95-RIT-1030-S 2-9/16″ 54
10″ 3″ 4000 Omega 12-3/4″ 2-95-UOR-1030-S 2-95-UOT-1030-S 2-9/16″ 61
10″ 3″ 4000 Rubber on Aluminum-EHT 12-3/4″ 2-95-RAB-1030-S-EHT 2-95-RAT-1030-S-EHT 2-9/16″ 61
10″ 3″ 4000 Rubber on Iron-EHT 12-3/4″ 2-95-RIR-1030-S-EHT 2-95-RIT-1030-S-EHT 2-9/16″ 54
10″ 3″ 5800 Durastan 12-3/4″ 2-95-DUR-1030-S 2-9/16″ 31
10″ 3″ 6000 Solid Urethane 12-3/4″ 2-95-MUB-1030-S 2-9/16″ 31
10″ 3″ 6000 Urethane on Iron 12-3/4″ 2-95-UIR-1030-S 2-95-UIT-1030-S 2-9/16″ 61
10″ 3″ 6800 GT 12-3/4″ 2-95-GTB-1030-S 2-9/16″ 45
10″ 3″ 6800 Ultra Thick Urethane 12-3/4″ 2-95-UTR-1030-S 2-95-UTT-1030-S 2-9/16″ 64
10″ 3″ 8000 Cast Iron 12-3/4″ 2-95-CIR-1030-S 2-95-CIT-1030-S 2-9/16″ 74
10″ 3″ 12000 Forged Steel 12-3/4″ 2-95-FSR-1030-S 2-95-FST-1030-S 2-9/16″ 76
10″ 3″ 20000 Nylatron HD 12-3/4″ 2-95-NYB-1030-S 2-9/16″ 46
10″ 4″ 3420 Rubber on Iron 12-3/4″ 2-95-RIR-1040-S 2-95-RIT-1040-S 2-9/16″ 72
10″ 4″ 8400 Urethane on Iron 12-3/4″ 2-95-UIR-1040-S 2-95-UIT-1040-S 2-9/16″ 76
10″ 4″ 9000 Ultra Thick Urethane 12-3/4″ 2-95-UTR-1040-S 2-95-UTT-1040-S 2-9/16″ 76
10″ 4″ 10000 Cast Iron 12-3/4″ 2-95-CIR-1040-S 2-95-CIT-1040-S 2-9/16″ 116
10″ 4″ 10000 Forged Steel 12-3/4″ 2-95-FSR-1040-S 2-9/16″ 110
10″ 4″ 20000 Nylatron HD 12-3/4″ 2-95-NYB-1040-S 2-9/16″ 76
10″ 4″ 20000 Forged Steel 12-3/4″ 2-95-FST-1040-S 2-9/16″ 110
12″ 3″ 2280 Rubber on Iron 15-1/2″ 2-95-RIR-1230-S 2-95-RIT-1230-S 3-7/16″ 83
12″ 3″ 4560 Rubber on Aluminum-EHT 15-1/2″ 2-95-RAB-1230-S-EHT 2-95-RAT-1230-S-EHT 3-7/16″ 88
12″ 3″ 4560 Rubber on Iron-EHT 15-1/2″ 2-95-RIR-1230-S-EHT 2-95-RIT-1230-S-EHT 3-7/16″ 83
12″ 3″ 6800 Urethane on Iron 15-1/2″ 2-95-UIR-1230-S 2-95-UIT-1230-S 3-7/16″ 88
12″ 3″ 7000 Durastan 15-1/2″ 2-95-DUR-1230-S 3-7/16″ 34
12″ 3″ 8200 Ultra Thick Urethane 15-1/2″ 2-95-UTR-1230-S 2-95-UTT-1230-S 3-7/16″ 101
12″ 3″ 10000 Cast Iron 15-1/2″ 2-95-CIR-1230-S 2-95-CIT-1230-S 3-7/16″ 83
12″ 4″ 9600 Urethane on Iron 15-1/2″ 2-95-UIR-1240-S 2-95-UIT-1240-S 3-7/16″ 96
12″ 4″ 10600 Ultra Thick Urethane 15-1/2″ 2-95-UTR-1240-S 2-95-UTT-1240-S 3-7/16″ 106
12″ 5″ 12000 Urethane on Iron 15-1/2″ 2-95-UIR-1250-S 2-95-UIT-1250-S 3-7/16″ 155
12″ 5″ 13000 Ultra Thick Urethane 15-1/2″ 2-95-UTR-1250-S 2-95-UTT-1250-S 3-7/16″ 155
12″ 6″ 15000 Urethane on Iron 15-1/2″ 2-95-UIR-1260-S 2-95-UIT-1260-S 3-7/16″ 180
14″ 3″ 9600 Ultra Thick Urethane 18″ 2-95-UTR-1430-S 2-95-UTT-1430-S 3-7/8″ 126
14″ 4″ 12400 Ultra Thick Urethane 18″ 2-95-UTR-1440-S 2-95-UTT-1440-S 3-7/8″ 156
14″ 5″ 15200 Ultra Thick Urethane 18″ 2-95-UTR-1450-S 2-95-UTT-1450-S 3-7/8″ 170
14″ 6″ 18000 Urethane on Iron 18″ 2-95-UIR-1460-S 2-95-UIT-1460-S 3-7/8″ 178
16″ 3″ 8000 Durastan 19″ 2-95-DUR-1630-S 4-1/8″ 89
16″ 3″ 9200 Urethane on Iron 19″ 2-95-UIR-1630-S 2-95-UIT-1630-S 4-1/8″ 115
16″ 3″ 10800 Ultra Thick Urethane 19″ 2-95-UTR-1630-S 2-95-UTT-1630-S 4-1/8″ 94
16″ 4″ 12000 Urethane on Iron 19″ 2-95-UIR-1640-S 2-95-UIT-1640-S 4-1/8″ 165
16″ 4″ 14200 Ultra Thick Urethane 19″ 2-95-UTR-1640-S 2-95-UTT-1640-S 4-1/8″ 165
16″ 5″ 16800 Urethane on Iron 19″ 2-95-UIR-1650-S 2-95-UIT-1650-S 4-1/8″ 185
16″ 5″ 17600 Ultra Thick Urethane 19″ 2-95-UTR-1650-S 2-95-UTT-1650-S 4-1/8″ 205
